1.Match three engine 45 horsepower domestic famous countries, discharge upgrade, low fuel consumption, large torque backup, low power is strong。
2.Adopt double clutch, by using 8 + 2, options 8 + 8 shuttle shift, creeper gear, side hang when variable speed, speed matching is reasonable, high work efficiency。
3.Double speed power output, according to the operation needs can choose r/r/min min and 540/1000 540/760。
4.Enhanced oil cylinder of front drive axle, gap, high bearing capacity is strong。
5.Hydraulic oil supply independently, full hydraulic pressure independent steering, small turning radius。
| Engine power (kw) | 29.4 / 33 / 36.7 / 40.4 | The Optional Engine | Laidong,Quanchai, Xinchai |
| Transmission Box | 8+4 16+8 | PTO Rev. (r / min) | 540 / 760 r / min 540 / 1000 r / min |
| Height (mm) | Wheel Base (mm) | 1660 | |
| Front Wheel Tread (mm) | 1200、1300 | Rear Wheel Tread (mm) | 1200、1300 |
